| Place of Origin: | CHINA |
|---|---|
| اسم العلامة التجارية: | WEJOIN |
| إصدار الشهادات: | ISO;SGS |
| Model Number: | WJTY202 |
| Minimum Order Quantity: | 1 apir |
| الأسعار: | Negotiation |
| Packaging Details: | wooden package |
| Delivery Time: | 3-5 working days after payment received |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 2000+pair+per month |
| Housing material: | SST 304 | Width length: | 600mm |
|---|---|---|---|
| Wing material: | organic glass | Motor Voltage: | DC12V |
| Passing speed: | 30-40 persons per minute | Dimension: | 1200*270*1000 |
| Package: | Wooden | Safaty Sensor: | Yes |
| تسليط الضوء: | الأمن أقفال الباب,نصف الارتفاع الباب الدوار,half height turnstile |
||
Automatic Flap Barrier Optical Turnstile with Organic Glass Wing , 600mm Lane Width
Function&Fenture:
1. The turnstile will closed the door when somebody enter the gate illegal, Tailgating or break into negative direction gate.
2. Before received the open signal, the turnstile will lock automatically
3. The arm have the collision avoidance function: when the turnstile arm closed, if it is under the collision, the arm will open to protect the Transmission of inner machine.
4. Automatic Reset Functions: after you swap the card, during the specific time (standard is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate, (reset time is 5~20s you can adjust it what time is suit for you).
5. Infrared for Safaty access.
6. The turnstile can work with door access control system/ consumption system /biometric recognition system/ ESD system and so on.
7. The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles).
8. With Back-up battery.
9. Adjustable access directions
10. Traffic light indicating passenger access
Specifications
1) Electrical source voltage: AC220±10% V50HZ
2) Driving motor: direct current motor 12V/100W
3) Temperature of the working environment: -25OC - 50 OC
4) relative humidity: ≤90%, not dewing
5) input interface: 12V electrical level signal or 12V pulse signal with the
pulse width100ms driving electric current10mA
6) communication distance: ≤1200 meters
7) gateway width: wing barrier: 600mm
8) Passing speed: 30~40people/min
9) Time of gate opening and closing: wing barrier :0.5s
